Clash Royale API: Looping Query for Data Collection

Original article was published on Artificial Intelligence on Medium

Data Science

Clash Royale API: Looping Query for Data Collection

A few days ago I had the idea of applying factor analysis to the decks of the Clash Royale players in order to classify them into hierarchies. Unfortunately, I realized that I could not find any related data online, and none of the open-source datasets I found had the information I was searching for: therefore, I decided to use an API to download raw data from the source.

You can use this tutorial as a guide to orient you in the use of APIs and data collection from online databases. In a further tutorial, I will perform a factor analysis on the results to identify hierarchical structures in the collected data.

Full code available on my GitHub repo.

Downloading Clash Royale matches as .json

Image from Wallpaper Cave

Clash Royale is a smartphone game that allows each player to build a deck of 8 different cards to battle against other players. Through the website https://developer.clashroyale.com/#/ I can have access to the last 25 matches a player has fought. I want to collect and store the data of every deck played by top players in the last 25 battles so that I can later use the data to train an AI. For doing this, I will need to:

1. Register and get an API token on developer.clashroyale.com

2. Establish a connection to the dataset through an API

3. Download a specific set of data (I cannot download everything, I need to be specific on what I want to collect)

4. Iterate through each .json I have downloaded, extract the features I want from the .json file and store them

5. Make all the stored data with identical shape, then create a DataFrame

6. Export the DataFrame

Practical Issues

Realistically, there are so many limitations we encounter when downloading data using APIs:

  • There is a time limit: we can download small batches of data in relation to time

This problem makes it very challenging to work with this database. I know that for my AI I need thousands of matches to perform any kind of analysis, however, I can download up to 25 matches every 4 minutes, 15 of them probably valid (I only want to store ‘Ladder’ games, discard all the others): this sets a download limit of 225 matches per hour, given that the algorithm is fully running and every request is valid (you would not believe how many issues happen even when performing a valid request).

Through this article I will guide you in building an algorithm capable of periodically connecting to an online database to extract information, collecting them into a DataFrame that you can export as a .csv file.

  • We need to know what data to search for

In this specific case, I will need to input the tags of the players that have played the matches I want to collect data from. I will choose 7 of the top players that play one archetype called the X-bow (the top player using this archetype is called LemonTree68, his name will be echoed through time…). As already mentioned, I only want to save games played in ‘Ladder’, so I will need to get rid of all the others: from 25 original games, I will likely be able to store only 15.

  • We need to process the .json files

The API will provide us with a list of dictionaries, each one representing a single match. However, we cannot just convert it to a .csv: we need to identify the features we want to save and then store them into a list for every .json dictionary we downloaded: we need to create a personalized algorithm for this.

If you are aiming to a more professional approach to Data Science, you will need to get used to downloading data directly from specific websites using APIs, rather than finding it already structured in some open-source repository.

Connecting to the Database

Let us begin going through the list of steps: first of all, I have registered in the website above and asked for a Developer Key linked to my IP address:

Key created on https://developer.clashroyale.com/#/

When I will use this key in my code, if the query (request) is proper and the IP address corresponds, the database will authorize me, and allow me to download data. For now, I will set up a connection with the database:

import requests
import json
from urllib.parse import quote
import time
headers = {
'Accept': 'application/json',
'authorization': 'Bearer <eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzUxMiIsImtpZCI6IjI4YTMxOGY3LTAwMDAtYTFlYi03ZmExLTJjNzQzM2M2Y2NhNSJ9.eyJpc3MiOiJzdXBlcmNlbGwiLCJhdWQiOiJzdXBlcmNlbGw6Z2FtZWFwaSIsImp0aSI6ImFkODhlY2NjLTM2YjUtNDUwZi1hODI0LTY3ZWIyZjc0MzY5YSIsImlhdCI6MTU4OTQ4MzUyMiwic3ViIjoiZGV2ZWxvcGVyLzJkZGRhOGI4LTEyY2YtMzQzNy05N2FjLTQxNTBhMTMzNGI1MiIsInNjb3BlcyI6WyJyb3lhbGUiXSwibGltaXRzIjpbeyJ0aWVyIjoiZGV2ZWxvcGVyL3NpbHZlciIsInR5cGUiOiJ0aHJvdHRsaW5nIn0seyJjaWRycyI6WyIxMDQuMTU1LjIxOC4xNzgiXSwidHlwZSI6ImNsaWVudCJ9XX0.PdB9ycHIcIkKRs246zKLNdRJleUiXV9u-szeMj9qm02Rz-wS4OkkfOaafWRMXos_LVLmZe1VeUBCpr6fIiMvRw>'
}

Preparing the Request

As mentioned before, I need to be very specific on which data I want to download. I will download the most recent matches of 7 of the top X-bow players (25 matches per player) in the world. Therefore, I will store the following tags.

#has to be run only once, otherwise the dataset we are going to create will reset
battles_list = list()
tag_list = [
'#929URQCL8', '#RC2JGVVG', '#R9QC0QUQ',
'#9JPL980Y2', '#YU8R0VPP', '#RPURG9GR',
'#2GYRQJRR8']
tag_list_scavenged = list()
columns = [
'gamemode', 'battletime',
'p1.name', 'p2.name',
'p1.crowns', 'p2.crowns',
'p1.card_1', 'p1.card_2', 'p1.card_3', 'p1.card_4',
'p1.card_5','p1.card_6', 'p1.card_7', 'p1.card_8',
'p2.card_1', 'p2.card_2', 'p2.card_3', 'p2.card_4',
'p2.card_5', 'p2.card_6', 'p2.card_7', 'p2.card_8'
]

Because I already looked at the data, I will also save the headers of the features I will want to apply to the last version of the .csv dataset we are going to create: essentially the game mode (we will use this information to discard all games not played in ‘Ladder’), the battle time and the name of the two players (in order to discard duplicates), the number of crowns to figure our who won the match, and finally the deck chosen by each player.

For each label forward a query

I will now create a function that will allow me to perform a GET request to the database: for each player tag I will download a .json file, make the proper modifications, and end up with a list with 25 elements: each element contains only the data I want as the summary of a battle.

import pandas as pd
from pandas.io.json import json_normalize
def p1_dataset(player_tag):
df_list_complete = list()
#downloading json
r = requests.get('https://api.clashroyale.com/v1/players/'+player_tag+'/battlelog', headers=headers)
#a contains 25 dicts in a list
try:
a = r.json()
###IN CASE OF UNRESOLVED ERROR: EXIT
except Exception as e:
return 1
###IN CASE OF FAILED REQUEST: EXIT
if a == {'reason': 'accessDenied', 'message': 'Invalid authorization'}:
return 0

In case the dataset returns error, the functions exits returning 0 or 1.

Structuring each JSON into a DataFrame

 #for each of the 25 dicts in the list
for n in a:

Download all data into variables

The biggest issue so far is structuring each .json. As you can see from what I have downloaded, it is a set of dictionaries withing dictionaries. What I will do, is using pandas.io.json.json_normalize, this tool will allow me to turn a dictionary contained in one cell into another DataFrame.

How .json will look like

Essentially, I will be dealing with several nested dictionaries:
