Building Chatbot GUI
Once again, we need to extract the information from our files.
Here are some functions that contain all of the necessary processes for running the GUI and encapsulates them into units. We have the clean_up_sentence() function which cleans up any sentences that are inputted. This function is used in the bow() function, which takes the sentences that are cleaned up and creates a bag of words that are used for predicting classes (which are based off the results we got from training our model earlier).
In our predict_class() function, we use an error threshold of 0.25 to avoid too much overfitting. This function will output a list of intents and the probabilities, their likelihood of matching the correct intent. The function getResponse() takes the list outputted and checks the json file and outputs the most response with the highest probability.
Finally our chatbot_response() takes in a message (which will be inputted through our chatbot GUI), predicts the class with our predict_class() function, puts the output list into getResponse(), then outputs the response. What we get is the foundation of our chatbot. We can now tell the bot something, and it will then respond back.
Here comes the fun part (if the other parts weren’t fun already). We can create our GUI with tkinter, a Python library that allows us to create custom interfaces.
We create a function called send() which sets up the basic functionality of our chatbot. If the message that we input into the chatbot is not an empty string, the bot will output a response based on our chatbot_response() function.
After this, we build our chat window, our scrollbar, our button for sending messages, and our textbox to create our message. We place all the components on our screen with simple coordinates and heights.
