How does a machine predict that 3D view just from a 2D photo? I mean, for each object in the photo, if you want to “see” what is behind it, you have to somehow imagine it as a human. When people see a photo, they not only just see it as a static image, but also perceive it as a 3D object that is alive, and even makes up an imaginary scene or recalls some memories. But how does a machine deal with such a complex concept? Can it “imagine”??

Well, a machine cannot imagine, but it can “learn” to “imagine”, or in other words, it can treat data and output in a way like a human. Basically, machine just does what they excel at: calculations.

Pic from 3D Photography using Context-aware Layered Depth Inpainting

Normally for AI learn RGB-D image, where the D represents ‘depth’, to relive 3D effects. Most smartphones in the market have two cameras right now to capture color and depth in view separately. However, what about normal RGB pictures without depth? Machine predicts! With some standard image preprocessing steps, we can find the depth plot easily (a to d)

With the predicted depth, machine can find where the depth discontinuities are, then categorize then and group to different color sections (e to f).

With all the preprocessing preparation, we are going to repair the 3D vision from our 2D photo. The most essential tool we are using is called Layered Depth Image (LDI)

Pic from 3D Photography using Context-aware Layered Depth Inpainting

On the edges, the pixel by two sides are connected by a sharp drop (a). The program first cut the drop connection into green and red regions (b), we call them foreground silhouette and background silhouette, spawn a synthesis region based on background silhouette, or context region (c), then merge into the model.

Pic from 3D Photography using Context-aware Layered Depth Inpainting

Now, since we have two regions separated already (context region and synthesis region), scientists use three repairing agents to complete the inpainting task: edge inpainting network, color inpainting network, and depth inpainting network. You can check out the resources below to see how those inpainting networks work in detail.

The edge inpainting network repairs the contour between context region and synthesis region, to predict the blocked edges. Then the machine uses color inpainting network and depth inpainting network to imagine the blocked color and depth respectively. After this, we feed the result back to the LDI model, and Bingo! We have the result!

Without further due, play with the model and relive your memories!
